Category 7a, Class EA

Shielded, tool-free connection

Insertion force: 30N max. (IEC 60603-7-5)

Quick and safe wire terminations without any special punch tools

Retention strength: 7.7 kg between jack and plug

Suitable for patch panels and mounting outlets RJ45 female to LSA, 8P8C Cable installation via LSA strips, color coded according to EIA/TIA 568 A & B

Operating temperature: -20 ~ +70°C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C)

Area of application: Up to 500 to 1200 MHz, 10GBase-T Norms: ISO/IEC 11801 2nd Ed., EN 50173-1, EIA/TIA 568-C, 802.3af, 802.3at PoE+

360° shield coverage

Accepts: 22-24 AWG solid cables (bare conductor diameter from 0.50-0.58mm, outside diameter from 5.0-8.5mm)

RJ45 contact: Tinned phosphor bronze with gold-plating

Zinc die-cast, nickel-plated

LSA termination clamp: Krone LSA+, UL 94V-2, zinc plated phosphor bronze PCB: FR4, UL 94V-0

RJ45 pin holder: ABS UL 94V-0

Mating cycles female: > 750 according to ISO/IEC 11801, IEC 60603-7-5 Clamp: > 200 according to ISO/IEC 11801, IEC 60603-7-5
